Double banjo bolt | JIC (UNF)

Banjo bolts are available in UNF, Metric and BSP type thread fitments, three different length; single and double variations.

Full range of Single Banjo bolts with metric thread - DATA SHEET

• Fitting type: Reusable Banjo Bolt
• Fluid applications: Brake, Clutch lines
• Compatible fittings: 600 series (AN-03, AN-04)
• Materials: Stainless Steel, Aluminium, Steel

Short version ("under hex" length 28 mm) - use for banjo fittings with ball height
8mm.
Standard version ("under hex" length 30 mm) - use for banjo fittings with ball height 8mm.
Long version ("under hex" length 38 mm) - use for banjo fittings with ball height 12 mm

*The banjo fitting seals to the banjo bolt using two washers, as per diagram below.
